KEY FEATURES OF THE MFD28

MFD28 is rich in functions that you can use, but you don't have to.
Hardware: 2.8 TFT screen, touchscreen, MicroSD, MicroUSB
High-quality milled aluminum front frame
Symmetrical display - therefore ideal for rotating it by 90°
Views can be completely freely configured on the PC with our HYPERLINK DSS display setup software
up to 64 widgets per display
64 sensors (Can Bus + internal)
10 views


- supported values -
Many customers always ask: Which values can I query from my control unit?" The answer: " ALL ". Our MFD28 is compatible with ISO 11898-2 and SAE J2284.
The ECU manufacturers themselves determine which values are sent via the CAN bus interface. Documentation is important here - perhaps even in the form of a DBC file that can be imported directly. You can also access our extensive list of already implemented control devices. These can be found in the HYPERLINK https://www.accesspeed.com/downloads download area . A total of up to 50 sensors can be queried if the manufacturer supports this.
Data that is available in broadcast as well as OBD2 queries via Can Bus (11bit/29bit) are implemented. Special protocols such as TP2.0 from VW/Audi and UDS are also available.

MFD28 dimensions
MFD28 - dimensions and fastening

With its installation dimensions of 70.3 x 52mm, the display is very compact. The four holes on the front and the four black Torx screws included give the whole thing the perfect touch
